| Verstärkersektion |
Channel |
7.2 |
| Rated Output Power (1kHz, 1ch driven) |
160 W (4 Ohm, 0,9% THD) |
| Rated Output Power (20Hz-20kHz, 2ch driven) |
100 W (8 Ohm, 0,06% THD) |
| Maximum Effective Output Power (1kHz, 1ch driven) (JEITA) |
160 W (8 Ohm, 10% THD) |
| Dynamic Power per Channel (8/6/4/2 ohms) |
130 / 170 / 195 / 240 W |
| Surround Sound Ausstattung |
CINEMA DSP |
Ja (3D) |
| DSP Programs |
17 |
| Dialog Level Adjustment |
Ja |
| Virtual Presence Speaker |
Ja |
| Surround Sound Processing |
Virtual Surround Back Speaker |
Ja |
| Surround Sound Ausstattung |
Dialogue Lift |
Ja (keine Presence Speakernötig) |
| SILENT CINEMA / Virtual CINEMA DSP |
Ja (Virtual CINEMA FRONT) |
| Surround Sound Processing |
Dolby Atmos |
Ja |
| DTS:X |
Ja |
| Surround Sound Ausstattung |
Dolby TrueHD |
Ja |
| Dolby Digital Plus |
Ja |
| Dolby Pro Logic IIx |
Ja |
| DTS-HD Master Audio |
Ja |
| Audio Ausstattung |
Pure Direct |
Ja (mit Video on mode) |
| Compressed Music Enhancer |
Ja (inkl. Enhancer für Bluetooth) |
| YPAO multi-point measurement |
Ja (R.S.C) |
| Audio Features |
YPAO Volume |
Ja |
| Audio Ausstattung |
Adaptive DRC (Dynamic Range Control) |
Ja |
| Initial Volume & Maximum Volume Setting |
Ja |
| A.R.T. Wedge |
Ja |
| Bi-amp capability |
Ja |
| Audio Delay |
Ja (0-500 ms) |
| 192kHz/24-bit DACs for all channels |
Ja (Burr-Brown) |
| Video Features |
4K Ultra HD Pass-through and upscaling |
Ja (4K/60p, 4:4:4) |
| Video Ausstattung |
HDMI 3D passthrough |
Ja |
| HDMI Audio Return Channel |
Ja |
| HDMI upscaling |
Ja (Analog zu HDMI / HDMI zu HDMI) |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync |
Ja |
| Anschlüsse |
HDMI Input/Output |
8 (HDMI1,2,3:HDCP2.2 kompatibel) / 2 (HDCP2.2 kompatibel) |
| HDMI CEC |
Ja (SCENE, Device Control) |
| USB Input |
USB Memory, Tragbarer Audio Player |
| Network Port |
Ja |
| Connectivity |
Wi-Fi |
Ja (mit Wireless Direct) |
| Anschlüsse |
AirPlay |
Ja |
| Connectivity |
Bluetooth |
Ja (SBC / AAC) |
| Anschlüsse |
Front AV Input |
HDMI / USB / Analog Audio / Composite |
| Digital Audio Input/Output: Optical |
2 / 0 |
| Digital Audio Input/Output: Coaxial |
2 / 0 |
| Analog Audio Input/Output |
6 (Front 1) / 0 |
| Phono Input |
Ja |
| Component Video Input/Output |
2 / 1 |
| Composite Video Input/Output |
5 (Front 1) / 1 |
| Preout |
7.2 Kanal |
| Headphone Output |
1 |
| Radiosektion |
FM/AM Tuner |
Ja |
| Bedienung |
On-screen display |
Graphical User Interface |
| SCENE |
SCENE (4 Tasten) |
| App Control |
Ja (iPhone / iPad / Android Phone / Tablet) |
| Web Browser Control |
Ja |
| Remote Control Unit |
Ja |
| Multiroom Ausstattung |
Zone 2 Audio Output |
Line output |
| Powered Zone |
Zone 2 |
| Zone B Output |
Ja (HDMI) |
| RS-232C Interface |
Ja |
| +12V Trigger Output |
1 |
| Remote (IR) Input/Output |
1 / 1 |
| Basics |
Standby Power Consumption (IR only) |
=0,1W |
| Auto Power Standby |
Ja |
| ECO mode |
Ja |
| Dimensions (W x H x D) |
435 x 171 x 382 mm (mit Antenne: 435 x 234 x 382 mm) |
| Weight |
10,5 kg |
